Visaton TW 6 NG Replacement Cone Tweeter
Sound Imports | € 14,95 |
---|---|
Productpine | € 44,31 |
Beschrijving
Productpine 50 mm conus tweeter. Dankzij de gesloten achterzijde heeft de driver geen aparte behuizing nodig. Nominal power handling with high pass: 60 W (12 dB/Okt.; 5000 Hz) Peak power handling with high pass: 100 W (12 dB/Okt.; 5000 Hz) Nominal impedance Z: 8 Ohm Frequency response: 1000–30000 Hz Mean sound pressure level: 91 dB (1 W/1 m) Opening angle (-6 dB): 97°/8000 Hz Excursion limit: +/−0. 5 mm Resonance frequency fs: 1500 Hz Magnetic induction: 0. 8 T Magnetic flux: 70 µWb Height of front pole-plate: 2. 5 mm Voice coil diameter: 14 mm Height of winding: 2. 5 mm Cutout diameter: 56 mm Net weight: 0. 14 kg D. C. resistance Rdc: 6, 5 Ohm Effective piston area Sd: 17 cm² Inductance of the voice coil L: 0. 17 mHVergelijk aanbieders (2)
Shop |
Prijs |
Verzendkosten |
Totale prijs |
|
---|---|---|---|---|
€ 14,95
|
Gratis | € 14,95 |
Ga naar shop
Gratis
|
|
€ 44,31
|
Gratis | € 44,31 |
Ga naar shop
Gratis
|
50 mm conus tweeter. Dankzij de gesloten achterzijde heeft de driver geen aparte behuizing nodig. Nominal power handling with high pass: 60 W (12 dB/Okt.; 5000 Hz) Peak power handling with high pass: 100 W (12 dB/Okt.; 5000 Hz) Nominal impedance Z: 8 Ohm Frequency response: 1000–30000 Hz Mean sound pressure level: 91 dB (1 W/1 m) Opening angle (-6 dB): 97°/8000 Hz Excursion limit: +/−0. 5 mm Resonance frequency fs: 1500 Hz Magnetic induction: 0. 8 T Magnetic flux: 70 µWb Height of front pole-plate: 2. 5 mm Voice coil diameter: 14 mm Height of winding: 2. 5 mm Cutout diameter: 56 mm Net weight: 0. 14 kg D. C. resistance Rdc: 6, 5 Ohm Effective piston area Sd: 17 cm² Inductance of the voice coil L: 0. 17 mH
Sound Imports55 mm (2.2”) Cone tweeter for the high-frequency range above 5,000 Hz. Balanced response for easy system integration Great replacement driver Sealed rear Visaton () TW 6 NG 2.2" Cone Tweeter 8 Ohm This tweeter has a balanced frequency response with brilliant treble and high power handling. Due to the sealed rear no separate high-frequency range housing construction necessary. Especially suitable as replacement unit for many HiFi speakers. Visaton artikelnummer: 1000
