LED driver met constante stroom 350 mA max. 72 V

Mean Well LED-Driver met Constante Stroom - 1 Uitgang - 350 mA - 25 W PLM-25 is a 25 W economical AC/DC LED power supply series. Incorporating a built-in active PFC design, PLM-25 provides a high power factor value greater than 0.9. In addition, with the low no load power consumption below 0.5 W, and the setup time less than 500ms, PLM-25 is complied with the ERP regulation required by European Union for lighting fixtures. PLM-25 is a class II (without FG pin) power unit housed with the UL 94V-0 rated flame retardant plastic case. The I/O terminals are designed with screw-less clamp style terminal block that greatly simplifies the wiring installation. Two types of models with different input voltage range are offered: PLM-25 series, which operates from 110-295 VAC, and PLM-25E series, which operates from 180-295 VAC. These two series are both constant current output design, supplying models with the current of 350 mA, 500 mA, 700 mA and 1050 mA, respectively. Features: * 230 VAC of volledig bereik (max. 295 VAC) * met actieve PFC-functie * constante stroom * beveiligingen: kortsluiting * koeling door natuurlijke convectie * volledig geïsoleerd plastic omhulsel * klasse II, zonder aardingspin * klasse 2 (voor PLM-25-500/700/1050) * verbruik bij nullast:
