Hifonics Zeus ZSPL12D2 subwoofer 12 inch 600 watts RMS DVC 2 ohms

Bol Partner

Hifonics Zeus ZSPL-12D2 12 inch subwoofer Productinfo: 12" (30cm) subwoofer Dual magnet drive with 120 ounces (3.4 kg) 64 mm voice coil with X-Max. +/- 26 mm Double-stitched bead Robust steel basket Carbon composite dust cap Ultra-stiff RSA surround Handmade, impregnated paper membrane Blue magnet protector Technical data Power handling RMS 600 watts Load capacity MAX 1200 watts Load capacity peak 1800 watts Impedance D2 2x2 Ohm SPL 89dB (2.83V/1m) Basket size 30 cm (12") Outer diameter Ø 320 mm Installation opening Ø 276 mm Installation depth 166 mm Double voice coil Ø 64 mm, ‡38 mm Double magnet Y35, 2 x 60 oz. (3.4 kg) Frequency range 30 - 300 Hz Recommended amplifier power4 600 - 900 Watt/RMS TSP Xmax Maximum deflection ± 26 mm SPL 2.83 V/1m 89 dB SD 512 cm2 Mms 188 g Re 2 x 1.8 Ω Fs 34 Hz Qms 4.24 Qes 0.61 QTS 0,53 VAS 42,7 L Housing recommendation Closed housing Compact Volume Vb 40 - 50 L Cut-off frequency F3 45 Hz Bass reflex enclosure Low bass Volume Vb 55 L Frequency - 3dB F3 31 Hz Tuning frequency Fb 36 Hz Duct diameter Ø 12 cm Channel area 113 cm2 Channel length 34 cm

Amazon

Subwoofer van 30 cm (12), vermogen 600 W/RMS, 1200 W/MUSIC, 1800 W/PEAK, impedantie 2 + 2 ohm, SPL 89 dB (2,83 V/1 m), inbouwopening 276 mm, inbouwdiepte 166 mm. mm
