DisplayPort 1.2 Splitter 1 x Mini in> 4 uit 4K

Description This splitter by Delock receives a DisplayPort signal from a PC or laptop and splits it to four connected displays. Thereby one DisplayPort connection can be used to operate four DisplayPort monitors. The outputs are dual-mode capable (DP++), so that HDMI or DVI monitors can be connected with suitable adapters. Specification • Connectors: Input: 1 x mini DisplayPort 20 pin male 1 x 5 V DC jack Output: 4 x DisplayPort 20 pin female • Chipset: STDP4320 • DisplayPort 1.2a specification • Active converter, Single / Multi Stream Transport Hub (SST / MST) • Maximum resolution (depending on the system and the connected hardware): DisplayPort 1.1 or 1.2 Single Stream Transport (SST): up to 1920 x 1080 @ 60 Hz (mirrored) DisplayPort 1.2 Multi Stream Transport (MST): up to 2560 x 1440 @ 60 Hz or 3840 x 2160 @ 30 Hz (mirrored or extended) max. 4x 1920 x 1080 @ 60 Hz • DisplayPort output supports Dual Mode DP++ • Supports audio and video signals • Supports Eyefinity / Single Large Surface (SLS) • Audio input formats: 7.1 channel up to 192 kHz sample rate • Metal housing • Cable length without connectors: ca. 30 cm • Colour: black • Dimensions (LxWxH): ca. 143 x 67 x 23 mm • OS independent, no driver installation necessary Power supply specification • Wall power supply • Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.4 A • Output: 5 V / 2 A • Ground outside, plus inside • Dimensions: inside: ø ca. 2.1 mm outside: ø ca. 5.5 mm length: ca. 9 mm System requirements • One free mini DisplayPort female Package content • DisplayPort Splitter • External power supply • User manual

Delock Displayport 1.2 Splitter 1 x mini Displayport in > 4 x Displayport out 4K - Video/audiosplitser - 4 x DisplayPort - desktop
